Top Modular 10-Head Linear Weigher for Precise Weighing
The modular 10-head linear weigher features a stepless vibrating feeding system that ensures even material distribution and a wider weighing range. It is ideal for the precise quantitative weighing of powdery and granular materials such as white sugar, salt, seeds, rice, sesame, monosodium glutamate, and more. With a maximum weighing speed of 120 bags per minute, this efficient weigher can handle up to 10 different materials, providing accurate and reliable results for high-volume applications.
Model
JW-AXS10
MOQ
1 set
Payment
L/C, T/T
Place of Origin
China
Brand
Kenwei
Identify Code
XS10-2-1
Weighing Range
2-200g
Accuracy
X(1)
Max Speed
120 P/M
Hopper Volume
0.5 L
Control Panel
7"Touch Screen
Power Requirement
220V/50/60Hz
Packing Dimension(mm)
1450(L)*970(W)*850(H)
Gross Weight
250kg
Parameters Press No.
20
Max Mixing Products
10
Power
1000W
| Material | 304 stainless steel | Certification | CE, OIML, SGS |
| Availability | OEM/ODM | Delivery Time | 7-30days |
| Start Port | Zhongshan port | Supply Ability | 500 sets/year |
Feature
● Advanced new modular control system for enhanced performance.
● Automatic amplitude adjustment for optimal operation and efficiency.
● Capable of weighing mixed products in a single discharge for improved versatility.
● Adjustable parameters for easy customization based on specific production needs.
● Features a stepless vibrating feeding system, ensuring smooth and consistent material flow.
Technical Specification
|
Model |
JW-AXS10 |
|
Identify Code |
XS10-2-1 |
|
Weighing Range |
2~200g |
|
Accuracy *1 |
X(1) |
|
Max. Speed *2 |
120P/M |
|
Hopper Volume |
0.5L |
|
Parameters Press No. |
20 |
|
Max Products Mixed |
10 |
|
Control Panel |
7”Touch Screen |
|
Options |
Dimple Plate/Timing Hopper/Printer/Reject Device |
|
Power Requirement |
220V/1000W/50/60HZ/5A |
|
Packing Dimension(mm) |
1450(L)x970(W)x850(H) |
|
Gross Weight |
250kg |
| *1: Can refer to the national standard GB/T27738-2011 or the international Legal Organization No.61 International Recommendation OIML R61 2004(E) | |
| *2: Depends on product shape, product density, target weight, etc. | |
Application
This system is ideal for weighing sliced, rolled, or uniformly shaped products such as sugar, salt, seeds, rice, sesame, monosodium glutamate, milk powder, coffee, seasoning powder, and more. Perfect for efficient and precise weighing in food processing and packaging applications.
Frequently Asked Questions
We've Got Answers
Browse some answers to our most common questions, or you can drop us a line to ask something else.
About products customization
Can I customize the size of Kenwei machines?
Yes, we can tailor the dimensions of our machines to fit your available space and production layout. Whether you need compact machines or larger equipment, we can accommodate your size requirements.
About Product choice
What is the difference between a multi-head weigher and a linear weigher?
Multi-head Weigher: Ideal for high-speed and high-precision weighing of products with irregular shapes or varying sizes. It provides multiple weighings in parallel for faster processing.
Linear Weigher: It is suitable for powder and granule. It is typically slower than a multi-head weigher but is effective for certain types of applications that require more continuous flow or controlled weighing.
About Price and payment
Can I get a detailed quote before making a purchase?
Absolutely! We provide detailed quotes that break down the costs for the machines, customization, shipping, and any additional services. Please contact our sales team with your requirements to receive a customized quote.
About Logistics
How are large machines handled during shipping?
Large machines are typically shipped via sea freight using containerized shipping.
About Solution suggestions
What industries benefit the most from Kenwei solutions?
Kenwei solutions are ideal for a wide range of industries, including:
1）Food Packaging snacks, grains, and powdered beverages.
2）Pharmaceuticals: Precise weighing of tablets, and capsules.
3）Chemicals: Weighing and packaging granular and powdered chemicals.
4）Agriculture: Packaging seeds, grains, and fertilizers.
