10-Head Standard No-Spring Multihead Weigher 1.6L for Precise Weighing
The standard no-spring combination scale features a patented spring-free hopper design, making it ideal for weighing a variety of products such as melon seeds, peanuts, nuts, almonds, grapes, candies, pistachios, potato chips, shrimp chips, and more. The double-support feeding tray is easily adjustable, while the feeding hopper is designed for easy disassembly, ensuring convenience and cleanliness. With a maximum weighing speed of up to 120 bags per minute, the 14-head standard no-spring combination scale is an economical, versatile, and cost-effective solution.
| Material | 304 stainless steel | Certification | CE, OIML, SGS |
| Availability | OEM/ODM | Delivery Time | 7-30days |
| Start Port | Zhongshan port | Supply Ability | 500 sets/year |
Feature
● Customized load cell for high-precision weighing.
● Program recovery function with calibration options for 200g and 1000g weights.
● "No Products Auto Pause" feature enhances weighing stability and accuracy.
● Supports up to 100 program settings to accommodate various weighing needs.
● Independently adjustable linear amplitude for optimal performance.
● Multi-language support, making it suitable for global markets.
Mechanical Character
Technical Specification
|
Model |
JW-A10 |
JW-A14 |
|
Identify Code |
A10-2-1DW |
A14-2-1DW |
|
Weighing Range |
10-1000g |
10-1500g |
|
Accuracy*1 |
X(0.5) |
X(0.5) |
|
Max Speed*2 |
60P/M |
120P/M |
|
Hopper Volume |
1.6L |
|
|
Control Panel |
7” Touch Screen |
|
|
Options |
Dimple Plate/Timing Hooper/Printer/Reject Device |
|
|
Driving System |
Step Motor |
|
|
Power Requirement |
220V/1000W/ 50/60Hz /10A |
220V/1000W/ 50/60Hz /10A |
|
Packing Dimension(mm) |
1620(L)X1080(W)X1120(H) |
1700(L)X1080(W)X1210(H) |
|
Gross Weight |
400kg |
500kg |
| *1: Can refer to the national standard GB/T27738-2011 or the international Legal Organization No.61 International Recommendation OIML R61 2004(E) | ||
| *2: Depends on product shape, product density, target weight, etc. | ||
Application
This machine is ideal for weighing a variety of products, including candies, seeds, jelly, pet food, puffed foods, pistachios, peanuts, nuts, raisins, dried fruits, snacks, and more.
Frequently Asked Questions
We've Got Answers
Browse some answers to our most common questions, or you can drop us a line to ask something else.
About Cooperation Process
What is the lead time for product delivery?
The lead time depends on the complexity of the order and the level of customization required. Typically, our products are shipped within 4-8 weeks after receiving the order confirmation. However, this can vary, and we will provide an estimated delivery date when you place your order.
About After Sales Support
How about the after-sales service?
Warranty :2 years
Can I get remote troubleshooting assistance?
Yes, Kenwei offers remote troubleshooting for certain issues. Our technical team can guide you through diagnostics and help resolve issues via phone, video call, or online messaging.
About Product choice
What is the difference between a multi-head weigher and a linear weigher?
Multi-head Weigher: Ideal for high-speed and high-precision weighing of products with irregular shapes or varying sizes. It provides multiple weighings in parallel for faster processing.
Linear Weigher: It is suitable for powder and granule. It is typically slower than a multi-head weigher but is effective for certain types of applications that require more continuous flow or controlled weighing.
About Solution suggestions
What industries benefit the most from Kenwei solutions?
Kenwei solutions are ideal for a wide range of industries, including:
1）Food Packaging snacks, grains, and powdered beverages.
2）Pharmaceuticals: Precise weighing of tablets, and capsules.
3）Chemicals: Weighing and packaging granular and powdered chemicals.
4）Agriculture: Packaging seeds, grains, and fertilizers.
