Single Head Belt Linear Weigher for Vegetable Product Weighing
The Single Head Belt Linear Weigher is constructed from food-grade stainless steel, making it ideal for materials with slight stickiness, such as brown sugar, black sugar, and industrial salt, which have low fluidity. This linear scale features a single hopper with a 15-liter capacity, designed for weighing larger materials efficiently.
Model
JW-AX1
MOQ
1 set
Payment
L/C, T/T
Place of Origin
China
Brand
Kenwei
Identify Code
XM1-2-2
Weighing Range
500-12000g
Accuracy
X(1)
Max Speed
8P/M
Hopper Volume
15L
Power Requirement
220V/50/60Hz/1.2A
Parameters Press No.
100
Max Mixing Products
1
Power
250W
Machine Dimension(mm)
1150Lx700Wx1090H
| Material | 304 stainless steel | Certification | CE, OIML, SGS |
| Availability | OEM/ODM | Delivery Time | 7-30days |
| Start Port | Zhongshan port | Supply Ability | 500 sets/year |
Feature
● Advanced modular control system for enhanced performance.
● Parameters can be easily adjusted to suit production needs.
● Stepless feeding mode regulates material flow in real time, ensuring precise weighing.
Mechanical Character
The entire machine is constructed from stainless steel, food-grade materials, ensuring hygiene and safety.
Custom food-grade conveyor belts are designed to meet the specific needs of various materials.
The machine features an easy-to-remove structure for simple maintenance and cleaning.
A customized load cell enhances weighing accuracy.
Independent gates are included, automatically opening and closing based on signal feedback.
Material contact parts are easily detachable for quick disassembly and maintenance.
Technical Specification
|
Model |
JW-AX1 |
|
Identify Code |
XM1-2-2 |
|
Weighing Range |
500-12000g |
|
Accuracy *1 |
X(1) |
|
Max. Speed *2 |
8P/M |
|
Hopper Volume |
15L |
|
Parameters Press No. |
100 |
|
Max Products Mixed |
1 |
|
Control Panel |
7”Touch Screen |
|
Options |
Dimple Plate/Timing Hopper/Printer/Reject Device |
|
Power Requirement |
220V/250W/50/60Hz/1.2A |
|
Packing Dimension (mm) |
1150(L)x700(W)x1090(H) |
|
Gross Weight |
200kg |
|
*1: Can refer to the national standard GB / T27738-2011 or the International Legal Organization No. 61 International Recommendation OIML R61 2004 (E). |
|
| *2: Depends on product shape, product density, target weight, etc. | |
Application
It is ideal for materials with slight viscosity, such as brown sugar and industrial salt, as well as vegetable products like fresh corn kernels, cauliflower, onion slices, and other diced, block, or stemmed vegetables.
Frequently Asked Questions
We've Got Answers
Browse some answers to our most common questions, or you can drop us a line to ask something else.
About Product choice
Are Kenwei’s products suitable for small-scale or large-scale operations?
Yes! We offer machines that are scalable to meet the needs of both small and large-scale operations.
What types of products does Kenwei offer?
Kenwei specializes in high-precision and high-speed automated machinery for weighing, packaging, and quality control. Our main products include: multihead weigher, linear weigher, checkweighers,food metal detector,vertical packing machine and packing machine accessories.
About Logistics
How long does logistics delivery take?
Shipping times depend on your location and the shipping method you choose. Generally speaking, international shipping can take anywhere from a few weeks to a few months.
About products customization
Can I customize the size of Kenwei machines?
Yes, we can tailor the dimensions of our machines to fit your available space and production layout. Whether you need compact machines or larger equipment, we can accommodate your size requirements.
About Solution suggestions
Can Kenwei provide solutions for high-volume production?
Yes, Kenwei specializes in high-speed, high-throughput machines designed for large-scale operations. Our multi-head weighers, packing machines, and check weighers.
